Flameless Infrared Ceramic Gas Burner For Kamado Gas Grill BBQ

Product Categories

Gas Brooder Heater [57]
Poultry Brooder Heater [56]
Infrared Brooder Heater [30]
Overhead Conveyor Chain [26]
BBQ Grill Burners [23]
Portable Gas Heater [20]
Portable Bbq Grill [10]
Catalytic Gas Burner [19]
Ceramic Heater Plates [14]
Cute Cosmetic Bags [1]
Powder Coating Oven Gas Burner [24]
Bakery Oven Gas Burner [19]
Thermostat Temperature Controller [18]
Brass Solenoid Valve [17]
Powder Spraying Machine [20]
Ignition Pin [18]
Electronic Pulse Igniter [18]

Chongqing Haodong Technology Co., Ltd.

Contact Now

Flameless Infrared Ceramic Gas Burner For Kamado Gas Grill BBQ

Brand Name : THD

Model Number : HD538

Place of Origin : Chongqing, China

MOQ : 1 pcs

Price : Negotiable

Payment Terms : L/C, D/A, D/P, Western Union

Supply Ability : 100 pcs per day

Delivery Time : According to your qty

Packaging Details : 19 pcs a carton, carton size: 47*43*30cm

Size : 538*85*65mm

weight : 1.4kg

Heat output : 3400 Kcal/H

Season : All season

Contact Now

Infrared Technology Feature.

Chongqing HaoDong Technology Co., Ltd, is only one in China and one of few companies worldwide who can actually manufacture CATALYTIC emitter. It's called Infrared Catalytic technique, different from infrared ceramic heater or infrared heater.This product is made for barbecue oven, grill,chicken gas roaster, shawarma/ doner/kebab/gyros machine,bread oven,cake bakery equipment,cheese baking machine.

SN	Items	Technical Parameters
1	Kinds of Gas	NG/LPG/Oil Field Gas/Artificial Gas
2	Perfect Combustion Temperature	≤380℃
3	Heat Source Temperature	850℃
4	Heating-up Temperature Range	35℃-500℃
5	Wavelength Range	4 um -15 um
6	Working Pressure	2000pa(NG)~~5000pa 2800pa(LPG)~~5000pa
7	Lifetime	Above 11000hrs
8	Waste Gas Emission	CO≤80ppm;NOx≤10ppm;CHx≤50ppm
9	Conversion Rate	> 90%

Product Description

Gas,LPG Infrared Ceramic Catalytic Burner for BBQ Grill HD538

Main Material:

1. Shell: aluminized steel sheet 2. Radiant part: cordierite honeycomb plates with black processed rare-earth catalyst coated 3. Nozzle: brass 4. Up cover: stamped stainless iron

Gas BBQ Grill Series Infrared Burner Main Specification:

Model	Dimension	N.W.	Heat Output		Gas Consumption		Gas Resource
	mm	kg	BTU/h	Kcal/hr	NG(m³/h)	LPG(kg/h)	Gas Resource
HD220	22017060	0.9	10000	2520	0.31	0.22	Natrual Gas,LPG, Propane, Butane
HD400	4008060	0.7	9030	2300	0.28	0.20
HD538	5388565	1.4	13500	3400	0.42	0.29
HD668	6688565	1.7	16600	4180	0.51	0.36
HD10	1706560	0.42	7500	1600	0.17	0.12
HD20	3006560	0.59	9400	1800	0.20	0.15
HD30	3406560	0.7	9500	2500	0.29	0.2

Flameless Infrared Ceramic Gas Burner For Kamado Gas Grill BBQ

Related Products:

Our Advantages

1. Easy being fixed.
2. Energy savings can be up to 20% per year
3. Environmental protection: CO≤80ppm;NOx≤10ppm;CHx≤50ppm
4. No need for a long and expensive preheating, it will reach comfort temperature very quickly.
5. Long useful time: ≥11000hr
6. Easy to clean
7. It can cut off the gas automatically and protect the burner when the flameout.
8. Silent, light and compact
9. High efficiency: it can come to working condition in 8seconds.

Application

This kind burner now are Mainly used for barbecue oven , grill, chicken gas roaster , shawarma/ donner/kebab/gyros machine, bread oven,cake bakery equipment, cheese baking machine…
and can be installed at all directions, but at bottom with a heat resistance glass cover is best.

For More Products

Products Name with link

91.8% Response Rate

Products Name with link

91.8% Response Rate

Products Name with link

91.8% Response Rate

Company Introduction

Chongqing Haodong Technology Co., Ltd which is found in 2005, is a professional manufacturer of Infrared Catalytic Gas Burner,BBQ Grill Gas Burner, Poultry heater, Gas brooder and Patio Heater etc.
Unique Rare-earth Catalyst Technology has gotten Patent certificate, it makes our burner to save 15~25% gas energy than non-catalytic type.Located in Chongqing City, southwest of China.
We owns advanced assembly lines, computer controlled injection machines, various high precision test equipment, sterilizing equipment and laboratory facilities. Professional engineers and technicians are employed could meet customer's new requirements demand.

Packing & Delivery

Packaging
Size	510 (L) * 440 (W) * 410 (D)
Weight	25kg
Packaging Details	The normal package is carton Corlor carton is customized
